DOWN4SOUND JP8 V1.5 - GRAY | 800W+ RMS AMPLIFIER

Key Features:

• Vintage-inspired OLD SKOOL GREY design from Down4Sound and Car Audio's OG days
• Built-in cooling fan for enhanced performance and longevity
• Plexi black plate and NEW ALUMINUM Bass Knob with voltage and temperature meter
• Standard 1-year manufacturer defects warranty
• Optional half-ohm warranty for added protection during .5 ohm hook-up

Testing Results by Big D Wiz: Independent testing by Big D Wiz confirms the Grey JP8's true power output. Here are the verified RMS power ratings at 14.4 volts:

• 4 OHM: 511 Watts RMS
• 2 OHM: 892 Watts RMS
• 1 OHM: 1256 Watts RMS

Our Testing Ratings (Worst Case Power Output):

• RMS power, 1 ohm: 700W x 1 @ 12v | 850W x 1 @ 14.4v
• RMS power, 2 ohms: 500W x 1 @ 12v | 650W x 1 @ 14.4v
• RMS power, 4 ohms: 490W x 1 @ 12v
• RMS power, 2 ohm Linked: 2300W x 1 @ 14.4v

Tuning Specifications:

• Frequency Response: 10 Hz - 270 Hz
• Low Pass Filter: 35 Hz - 250 Hz
• Subsonic Filter: 10 Hz - 50 Hz
• Bass Boost: 0 - 9 dB
• Input sensitivity: 6V - 0.2V
• Signal to Noise Ratio: 97dB
• T.H.D @ 4 ohm: less than 0.1%
• Single unit fuse rating: 120A
• Strapped fuse rating: 220A
• Operating voltage: 9 to 16 Volts
• Length x Width x Height (inches): 11.81" x 7.4" x 2.24"
• Damping Factor: 100
• Class: D - DIGITAL
